High-Temperature Nickel-Base
PowderRange® X
Couldn't load pickup availability

Specifications
Machine Type:
F - LPBF
E - EBM
Alternate Names:
Hast X, Alloy X, Nickel Alloy HX, HX
PowderRange® X is a solid solution strengthened nickel chromium-iron base superalloy. It is not considered precipitation hardenable and achieves optimum material properties through solution treatments. It possesses high strength at room and elevated temperatures, and exceptional oxidation and stress corrosion cracking resistance.
PowderRange® X displays significantly reduced crack susceptibility compared to the nominal alloy X composition. Its low carbon content and additional solid solution strengthening maximizes its compatibility with laser additive manufacturing processing. Although solution treatment is required for optimum high temperature performance, as-processed PowderRange® X displays mechanical properties equivalent to wrought material at both room and elevated temperatures.
- Nickel Balance
- Molybdenum 8.0 – 10.0 %
- Aluminum 0.50 %
- Silicon 0.20 %
- Oxygen 0.10 %
- Sulfur 0.030 %
- Chromium 20.5 – 23.0 %
- Cobalt 1.00 – 2.50%
- Copper 0.50 %
- Nickel Balance
- Titanium 0.150 %
- Phosphorus 0.040 %
- Boron 0.010 %
- Iron 17.0 – 20.0 %
- Tungsten 0.20 – 1.00 %
- Manganese 0.50 %
- Carbon 0.10 %
- Nitrogen 0.030 %
- Hydrogen 0.005 %
Key Properties
- Exceptional strength and corrosion resistance to 2200°F (1204°C)
- Non-magnetic
- Heat and corrosion resistant
Markets:
- Aerospace
- Energy
Applications:
- Turbine rotors
- Shafts
- Buckets
- Bolts
- Afterburner components
- Furnace hardware
